soft starter for asynchronous motor – ATS48 – 855 A – 230..415 V – 220..710 KW
Manufacturer: Schneider Electric
Part Number: ATS48M10Q
EAN: 3389110982558
Key Specifications
| Range of product | Altistart 48 |
| Ue power supply voltage | 230…415 V – 15…10 % |
| power supply frequency | 50…60 Hz – 5…5 % |
| Motor power kW | 630 kW at 400 V connection to the motor delta terminals for severe applications | 710 kW at 400 V connection to the motor delta terminals for standard applications | 220 kW at 230 V connection in the motor supply line for severe applications | 250 kW at 230 V connection in the motor supply line for standard applications | 355 kW at 230 V connection to the motor delta terminals for severe applications | 400 kW at 400 V connection in the motor supply line for severe applications | 500 kW at 400 V connection in the motor supply line for standard applications |
| Minimum switching current | 10 mA at 6 V DC for relay outputs |
| Net weight | 115 kg |
| Package 1 Weight | 115.0 kg |
| Package 2 Weight | 127.0 kg |
