Santernos SINUS B follows SINUS H series trendy Family Look, also sharing its overall quality of design, reliability and user-friendliness. It is compatible with “Remote Drive” software for remote control and monitoring (SINUS B PLUS only).
- EMC Filter
- Built-in braking unit
- DIN Rail Mountable
- Side by Side Installation
- Certifications: CE, RoHS, RCM, UL
- Display/Keypad with built-in potentiometer
- PID control
- Anti-forward and reverse direction rotation
- Manual torque boost, automatic torque boost
- Automatic restart
- Energy saving operation
- IP 20, UL Open Type
Specifications
| Manufacturer: | Santerno |
| Series: | Sinus B |
| Model: | SINUS B 2S 000A |
| Application: | general purpose |
| Capacity, kW: | 0.1 |
| Current, А: | 0.8 |
| Main power supply, V: | 200-240 |
| Phase: | 1 |
| Output frequency, Hz: | 0-400 |
| Enclosure: | IP20 |
| Overload capacity, % per 1 min.: | 150 |
| EMC filter: | + |
| Braking unit: | + |
| Analog input: | 1 |
| Digital input: | 3 |
| Analog output: | 1 |
| Digital output: | 1 |
| RS485 (Modbus RTU): | + |
| PID: | PID control |
| V/f control mode: | + |
| Operation temperature, °С: | -10…..+50 |
| Storage temperature, °С: | -20…..+65 |
| Dimensions (W x H x D), mm: | 85x135x100 |
| Weight, kg: | 1,46 |
